RF-400E Highflex Braided hoses w/ elbow

RF-400E Highflex Braided hoses w/ elbow

Style RF-400E Braided Flexible Sprinkler Hose is a high performance

sprinkler connection. Annular bellow design provides a high flexibility

and allows the hose to reach a minimum 2"/50mm bending radius. Friction

loss (EQL value) is remarkably reduced by an enlarged inner flow diameter

up to 1"/25.4mm. Suitable for up to 1" dry pendent sprinkler connection.

Listings:        (unlimited flexbility)
Connection:        1" / DN25  x ½" / DN15 or ¾" / DN25  or 1",/DN25, Elbow
Hose Diameter:                                                                   O.D. = 35.0mm / 1 ½"

Flow Diameter:                                                                         I.D. = 26.0mm / 1"
Rated working pressure (UL & FM):                                              14bars/203psi
Maximum ambient temperature:                                              66℃/150°F（UL）
