RF-200IB

RF-200IB

Stainless Steel Flexible hose,braided,for clean room application

Listings:       (unlimited flexibility)

Connection:                    1" / DN25 x ½" / DN15" / DN15,NPT or BSPT

Hose Diameter:                                               O.D. = 26.8mm / 1 ¹/₁₆"

Flow Diameter:                                                 I.D. = 21.0mm / ¹³/₁₆"

Rated Working Pressure:                            14bars/1.4MPa / 203psi(FM)

Prodruct detail
